Aqua Hot – Buehler 400/450 Pump Kit – PLE-100-905-FRU

$305.20

Buehler C20 400 – 450 Pump Retro Fit Kit, New Style Pumps are used on all new aqua-hot and hydro-hot systems. This can be used as a circulation pump, stir pump & engine pre-heat pump. *Due to this part being an electrical component, it is a non-returnable item.*

This kit includes:
PLX-100-900 – Pump, Buehler C20 – X1
PLX-100-836 – Bracket, Pump Mount – X1
PLX-100-837 – Isolator, Pump Bracket – X1
ELE-400-900 – Harness, Buehler C20 Pump – X1
PLE-450-150 – Hose, 3/4″ x 1/2″ Adapter, Straight – X2
PLX-CTB-250 – Clamp, Hose Constant Tension 23/32″ – X2
PLX-CTB-270 – Clamp, Hose Constant Tension 3/4″ – X2
PLX-CTB-290 – Clamp, Hose, Band 1-1/16″ – X2
PLX-000-433 – Hose, Heater 3/4″. Green Stripe – X26
ELX-252-010 – Terminal, Red, Male Quick Disc, 1/4 – X1
ELX-252-018 – Terminal, Red, Female Quick Disc, 1/4 – X1
ELX-200-150 – Connectors, Butt 18-22 ga – X1
PLX-000-825 – Fitting, Coupler 3/4″ in Black Nylon – X1
PLX-000-835 – Fitting, Reducer 3/4″ to 5/8″ Black Nylon – X1
EB9X027SS(00C) – Clamp, Worm Gear, 16-27mm – X4
SME-850-850 – Bracket, 450 Cooper to GRI Zone – X1
SR-5075B – Plastic Rivet – X4
MSX-210-985 – Tie, Cable 12″ – X2

Aqua Hot Parts Breakdown

In stock

Quantity

Guaranteed Safe Checkout

SKU: AQ-PLE-100-905-FRU Categories: , , , , Tags: , , , , , , , , , , , , , , , , , , , , Brands:

Description

Part #: PLE-100-905-FRU

Pump kit for Motorhome Hydronic Heating System | Aqua Hot – Buehler 400/450 Pump Kit – PLE-100-905-FRU

PLE-100-905-FRU is required for aftermarket installation replacing older versions of pumps for Zone Circulation, Stir or Engine Preheat. New-style pumps are used on all new aqua-hot and hydro-hot systems. This can be used as a circulation pump, stir pump & engine pre-heat pump.

The circulation pumps first draw the heated antifreeze and water heating solution from the Aqua-Hot’s boiler tank, then propel it through the Hydronic heating system’s interior heat plumbing. For interior heating, it is the room thermostats that trigger the Aqua-Hot’s interior heating system. When a thermostat recognizes that heat is required in a particular area, it sends a signal to the Aqua-Hot’s electronic controller calling for heat. The Aqua-Hot responds by activating the circulation pump for that zone, which sends the heated antifreeze and water heating solution through the Heating Loop corresponding to the zone requesting heat.

The stir pump circulates the antifreeze and water heating solution within the Aqua-Hot’s boiler tank to ensure even heating of the solution. To accomplish this, the stir pump draws the solution from the bottom of the tank and immediately deposits it back into the top of the tank.

The engine preheat switch activates the engine preheat pump, which draws the motor home’s engine coolant through the boiler tank to heat it before returning it to the engine block to transfer the heat there.

Your Hydronic Heating System, whether it is an Aqua Hot, Hydro Hot, or Webasto DBW 2010 has a white label with a model number on the heater. This label can be found on the top or the side of your Aqua Hot, Hydro Hot, or Webasto Heating System.

List of compatible model numbers,
Aqua Hot

431/12
AHE-100-00S
AHE-100-01S
AHE-100-02S
AHE-100-03S
AHE-100-04S
AHE-101-000
AHE-120-03X
AHE-120-04X
AHE-130-03X
AHE-130-04X
AHE-450-DE1
AHE-450-DE2
AHE-450-DE3
AHE-450-DE4
AHE-600-D01
AHE-600-D02
AHE-600-D03

Aqua Hot Cont.

400LP
400P
450P
400-D
450-D
600-D
400D
450D
600D

Hydro Hot

HHE-200-07E
HHE-500-07M
HHE-200-08E
HHE-500-08M
HHE-200-09E
HHE-500-09M

Webasto

DBW 2010
DBW 2020

Additional information

Weight 2 kg
Dimensions 26 × 19 × 12 cm
